Videojet 3020 Laser Marking Systems

10 Watt Industrial Laser Marking Machine for Simple Coding Applications

The Videojet 3020 10 watt Laser Marking System is specifically designed to meet simple coding applications across a wide range of substrates. It’s simple to set-up and operate, and flexible enough to accommodate changing production demands.

• Specs
• Benefits
• Applications
• Documents
• Videos

Specification	Value
Laser Tube	CO2
Maximum Power	10W
Laser Cooling	Fan
Maximum Print Speed	500 characters/sec
Maximum Line Speed	60 m/min (197 ft/min)
Environmental Protection	IP20
Beam Output	Steered Beam
Laser Source Expected Life	30,000 hours
Laser Wavelength Options	10.6 μm
Focal Distance Options	100 mm (3.93 in) – 200 mm (7.87 in)
Maximum Mark Window	125.6 x 87.1 mm (4.94 x 3.43 in)
Standard I/O Connectivity	Plug In Connection
User Interface	Touch Panel
Plant Air Used	No

Simple Usability keeps operators focused on production, not on the printer:

• Touchscreen user interface has built-in tools and wizards that guide you through code creation, job set-up and changeover to reduce operator errors
• Extra-large marking field enables accurate coding in multiple locations, enabling more content to be marked across a larger area
• Print at speeds up to 500 characters/sec
• Maximum line speed of 60 m/min (197 ft/min)

Uptime Advantage keeps productivity up and costs down:

• Portable and lightweight, the 3020 is designed to aid simple changeover. Setting up for different size products takes less than 20 minutes by adjusting the 3020’s mobile stand
• Long-life laser tube provides years of reliable operation

Delivering consistent high quality codes across a range of simple applications:

• Scribing technology produces clear, high quality marks on both moving and stationary products
• Internal laser cooling, built upon efficient laser design, does not require external air sources, saving money
• Compact, self-contained design integrates nicely in existing production lines; the 3020 can be positioned in a variety of angles and heights

Candy and Confectionery

Fish and Seafood

Dairy

Additional Applications

• Egg
• Beverage

Pet Food and Animal Feed

Cosmetics, Personal and Home Care

Baked Goods and Cereal
